Rideau LED blanc à 4 LED RGBW puissants et support QuickDMX
EUROLITE LED Color Curtain

Télécharger l'image
Images des détails (37 au total)
svg
svg
svg
40 cm
svg
svg
svg
svg
svg
svg
svg
svg
svg
EUROLITE

Rideau LED blanc à 4 LED RGBW puissants et support QuickDMX

EUROLITE LED Color Curtain

Le stock suffit pour env. 12 semaines.
249,00 €
Économiser maintenant : Cet article est également disponible sous forme d'ensemble.
ajouter au panier
Trouver un revendeur
Prix de catalogue hors TVA 19%
Prix éventuellement différents dans les magasins spécialisés.
Réf. 42110500
Imprimer l'article
Étiquette de l'article
Vous trouverez ici les modes d'emploi et les téléchargements pour
EUROLITE LED Color Curtain
Color Curtain

Eurolite LED Color Curtain

Decorative light in vintage style


Decorative light objects are becoming increasingly popular: they can be integrated into shows as well as used for permanent light installations. The Color Curtains from Eurolite are such light objects.
Nahaufnahme EYE-7 HCL
Light-intense design object
The system itself consists of a round light unit to which a supplied string curtain is attached. This string curtain is illuminated by 4 light-intensive 30-watt LEDs. The basic colors are red, green, blue and warm white. From these, countless other colors can be mixed.
EYE-7 Frontansicht
EASY ASSEMBLY
There are two options for mounting the Color Curtain: At the top, there are three hanging points from which the system can be suspended. In addition, there is a hole for mounting the Color Curtain on a tripod. White speaker stands such as Omnitronic's BS-2 and BPS-2 models are particularly well suited for this purpose. The Color Curtain's connections and controls are on the top, but there is a special cable hatch to pass the cables through from the top so they can then be elegantly routed along the stand.
Nahaufnahme EYE-7 HCL
CONTROL
The system can be operated either in stand-alone mode or with an external DMX controller. This way you can install the Color Curtain as a decorative object in a lounge, for example, and set it to autonomously change colors slowly with smooth transitions. Several Color Curtains can also be connected to each other in master-slave mode, with one unit controlling all the others. More complex light installations or shows with the Color Curtain can be realized if an external DMX controller is used for control.
EYE-7 Frontansicht
CONNECTIONS
It is worth taking a further look at the connections. Here we find P-Con inputs and outputs for power. The DMX connections are three-pin. The USB socket is particularly convenient: it allows you to use Eurolite's wireless Quick-DMX system. To do this, plug in the optionally available QuickDMX USB connector and convert the system to wireless DMX operation. This simple and inexpensive solution not only enables the reception of wireless DMX signals. The USB transceivers are transmitters and receivers at the same time. Thus, a master/slave solution can also be easily realized wirelessly.
Économiser maintenant : Cet article est également disponible sous forme d'ensemble.
Ensembles en cours de chargement. Veuillez patienter...
Caractéristiques

Rideau LED blanc à 4 LED RGBW puissants et support QuickDMX

  • Conception élégante du boîtier blanc
  • Découpe pour le passage des câbles
  • 4 LED puissantes 4in1 QCL RGB/WW
  • Mélange de couleurs en continu; changement de couleur réglable; fondu enchaîné des couleurs réglable; Dimmer électronique
  • Effet stroboscope
  • Programmes de spectacle intégrés
  • Choix de couleur direct pour 15 couleurs
  • Commandé via DMX; Commande de la musique via Microphone; Fonction maître/esclave; stand-alone; QuickDMX via USB (facultatif); W-DMX by Wireless Solution via USB (facultatif); CRMX by LumenRadio via USB (facultatif)
  • Écran LED 7 segments 3 chiffres
  • Déjà préprogrammé pour %: EASY SHOW 1; LED EASY OPERATOR 4x4; LED EASY OPERATOR 4x6; Light Captain; Light´J
  • Entrée et sortie secteur pour interconnecter facilement jusqu'à 8 appareils
  • Pour des domaines d'application tels que: Clubs/Écoles de danse; Mariage/Gala/événements; Installation; Restaurants, bars et hôtels
  • Fonctionnement silencieux
  • Possibilité d'utilisation: Sur trépied; volant

L'étendue des fournitures

  • 1 x appareil, 1 x mode d'emploi, 1 x câble secteur/câble d'alimentation, 1 x housse textile
Données techniques
Alimentation électrique:100-240 V CA, 50/60 Hz
Puissance totale de raccordement:25 W
Type de protection:IP20
Branchement électrique:Alimentation électrique via P-Con (bleu), version encastrable
Sortie de courant:1 x P-Con (gris), version encastrable
Type de lampe:Lampe LED
LED:4 x 4in1 QCL RGB/WW
Fréquence du flash:0 - 20 Hz
Canaux DMX:4; 8
Entrée DMX:1 x XLR (M) 3 broches version encastrable
Sortie DMX:1 x XLR (F) 3 broches version encastrable
Commande:DMX; Commande de la musique via Microphone; Fonction maître/esclave; stand-alone; QuickDMX via USB (facultatif); W-DMX by Wireless Solution via USB (facultatif); CRMX by LumenRadio via USB (facultatif)
Préprogrammé dans:EASY SHOW 1; LED EASY OPERATOR 4x4; LED EASY OPERATOR 4x6; Light Captain; Light´J
Couleur du boîtier:Blanc
Type d'écran:Écran LED 7 segments 3 chiffres
Dimension:Hauteur : 1,3 m
Diamètre : Ø 40 cm
Poids:4,60 kg
Classification du bruit:Classe 0 (pas du tout de bruit)
Spécifications juridiques
Produit spécial:Non destiné à l'éclairage de la pièce dans les ménages
Utilisation:Éclairage pour effets de spectacle
Unités de conditionnement
UCEANPoidsDimension
140263976716295,60 kg46cm x 46cm x 22cm
2402639767255812,60 kg48cm x 48cm x 46,5cm
Accessoire
L'accessoire est en cours de chargement. Veuillez patienter...
Assistance
Pièces de rechange
E6519394
Pcb (Power supply) 12V/8,33A LED Color Curtain (HK-U100W)
E6519395
Pcb (Control/Display) LED Color Curtain (LED-6BAT-M)
E6519396
LED 30W RGBW QCL LED Color Curtain
Autres 4 pièces de rechange
